LG-55TR3DQ

LG CreateBoard Standard

Key Feature

Resolution : 3,840 × 2,160 (UHD)
Brightness : 400 nit (Typ.)
Multi-Touch Point : Max. 50 Points
OS Ver. : Andorid 14 (EDLA)
Interface (Input) : HDMI (3), DP, RGB (VGA), Audio, RS-232C, RJ45 (LAN), USB Type-C (2), USB 3.0 Type-A (5), USB 2.0 Type-A
Interface (Output) : HDMI Out, Audio Out, Touch USB (3), RJ45 (LAN)

0.00 AED

SIZE
- 86"
- 75"
- 65"
- 55"

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Specifications

SIZE	86", 75", 65", 55"

4K UHD interactive display

clear and sharp interactive display with 400 nit brightness

50-point multi-touch interactive screen

smooth interactive screen for multi-user collaboration

advanced connectivity interactive display

HDMI, DP, USB-C, and LAN for seamless integration

android 14 powered interactive board

built-in OS for apps, meetings, and productivity

LG TR3DQ Interactive Display – Advanced Interactive Screen in Dubai, UAE

The LG TR3DQ interactive display is a next-generation collaboration solution designed for modern workplaces, classrooms, and training environments. Available in multiple sizes including 55", this interactive display features a 4K UHD interactive screen with a resolution of 3,840 × 2,160, delivering sharp visuals and enhanced clarity.

With a brightness level of 400 nit, the interactive screen ensures excellent visibility in indoor environments. The interactive board supports up to 50 touch points, allowing multiple users to interact simultaneously on the interactive display, making it ideal for teamwork, brainstorming, and group collaboration.

Powered by Android 14 (EDLA certified), the interactive display offers access to a wide range of applications and services, enabling seamless productivity and collaboration. At Logixer, we provide supply and installation of LG interactive displays across Dubai and the UAE.

Advanced Interactive Collaboration Experience

50-Point Multi-Touch Interactive Screen

The LG interactive display supports up to 50 simultaneous touch points, enabling real-time collaboration on the interactive screen. Multiple users can write, draw, and interact on the interactive board at the same time.

Smooth Writing and Annotation

The interactive display provides a natural and responsive touch experience, allowing users to annotate, sketch, and present content directly on the interactive screen with precision.

Powerful Performance and Smart OS

Android 14 with Google EDLA

The interactive display runs on Android 14 with EDLA certification, allowing access to Google services and applications. This enhances productivity on the interactive screen and supports modern collaboration tools.

Seamless Application Usage

Users can run apps, manage files, and conduct meetings directly on the interactive display without requiring additional devices.

High-Quality Display Performance

4K UHD Interactive Display

The interactive display delivers Ultra HD resolution, ensuring clear visuals and detailed content for presentations, meetings, and learning sessions.

Bright and Clear Visual Output

With 400 nit brightness, the interactive screen maintains strong visibility and consistent performance in professional environments.

Flexible Connectivity and Integration

Multiple Connectivity Options

The interactive display supports HDMI, DisplayPort, USB Type-C, USB Type-A, LAN, RS-232C, and audio interfaces, ensuring compatibility with various devices.

Easy Device Integration

The interactive board can be connected to laptops, mobile devices, and enterprise systems, enabling seamless collaboration and content sharing.

Designed for Modern Workspaces

Professional and Durable Design

The interactive display is built for continuous usage in business and educational environments, ensuring long-term reliability.

User-Friendly Operation

The interactive screen is easy to set up and use, allowing teams to start meetings and collaboration without complexity.

Ideal Applications

The LG interactive display is suitable for:

• Corporate meeting rooms

• Training and seminar rooms

• Educational institutions

• Smart classrooms

• Conference spaces

• Collaborative work environments

LG Interactive Display Supply and Installation in Dubai

At Logixer, we provide complete supply, installation, and technical support for LG interactive displays across Dubai and the UAE. Our team ensures smooth deployment of interactive screens and interactive boards tailored to your business needs.

The LG TR3DQ interactive display is a powerful and future-ready solution for organizations looking to enhance collaboration, productivity, and digital interaction.

Panel

Screen Size	55"
Panel Technology	VA
Back Light Type	Direct
Aspect Ratio	16:09
Native Resolution	3,840 X 2,160 (4K UHD)
Refresh Rate	60 Hz
Brightness	400 nit (Typ.)
Contrast Ratio	5,000 : 1
Color gamut	NTSC 72%
Viewing Angle (H x V)	178 × 178
Color Depth	10bit(8bit + FRC)
Response Time	6.5 ms
Surface Treatment (Haze)	25%
Lifetime	50,000 Hrs (L50, Min.)
Operation Hours (Hours / Days)	16 / 7
Portrait / Landscape	No / Yes

Mechanical Specification

Bezel Color	Black
Bezel Width (T / R / L / B)	25.6 / 15 / 15 / 43.5 mm
Weight (Head)	26.7 kg
Packed Weight	31.6 kg
Monitor Dimensions (W × H × D)	1,269 × 783 × 100 mm
Carton Dimensions (W × H × D)	1,428 × 185 × 868 mm
Handle	No
VESA™ Standard Mount Interface	400 × 200 mm
Protection Glass (Degree of Protection)	Safety Glass
Protection Glass (Thickness)	3.2mm
Protection Glass (Tempered / Chemical Strengthening)	Tempered strengthening
Protection Glass (Anti-Reflective)	Yes
Protection Glass (Shatter-Proof)	Yes

Feature

Internal Memory (64 GB), Built-In Wi-Fi (Slot Type), Auto Brightness Sensor, Power Indicator, Local Key Operation, MIC (Built-in, 8), webOS ver. (Android14 (EDLA)), RS232C Sync (LG RS232C Command), Multi-screen (PIP / PBP, External Source), Screen Share (CreateBoard Share), Setting Data Cloning, Crestron Connected, Power (Smart Energy Saving, Wake on LAN), Network Ready (Fast Power On), HDMI-CEC, webRTC (CreateBoard Share)

Environment Conditions

Operation Temperature	0 to 40°C
Operation Humidity	10% to 90%

Power

Power Supply	AC 100-240V~, 50/60Hz
Power Type	Built-In Power

Power Consumption

Typ.	135 W
Max.	290 W
Smart Energy Saving (70%)	Yes
DPM	0.5W
Power off	0.5W
BTU (British Thermal Unit)	461 BTU/Hr (Typ.), 990 BTU/Hr (Max.)

Standard (Certification)

Safety	CB / NRTL
EMC	FCC Class "A" / CE / KC
ErP / Energy Star	Yes / Yes

OPS Compatibility

OPS Type Compatible	Yes
OPS Power Built In	Yes

Software Compatibility

LG Connected Care

Yes

Connectivity

Input	HDMI (3), DP, RGB (VGA), Audio, RS-232C, RJ45 (LAN), USB Type-C (2), USB 3.0 Type-A (5), USB 2.0 Type-A
Output	HDMI Out, Audio Out, Touch USB (3), RJ45 (LAN)

Sound

Speaker

Yes (20 W × 2 + 20 W)

Language

English, Simplified Chinese, Czech, Denmark, Arabic(Egypt), Finnish, French, German, Greek, Italian, Korean, Netherlands(Dutch), Norwegian, Polski, Portugues(Europe), Portugues(Brazil), Romanian, Russian, Spanish, Swedish, Türkçe, Ukrainian, Traditional Chinese, Hungarian, Thai, Indonesian, Kazakh, Catalan, Basque, Japanese,Estonian, Lithunian

Accessory

Basic	Power Cord 3 M1, USB Cable(Type A-Type B) 5 M1, USB Type-C Cable(C to C) 1.8 M1, HDMI Cable 3 M1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Controller(include battery 2ea), Wifi module
Optional	Wall Mount (WM-L000S), Floor Stand (ST-000F, ST-860F)

Touch

Available Object Size for Touch	Ø2 mm↑
Writing Height	≤2 mm
Response Time	≤5 ms
Accuracy	±1 mm
Interface	USB 2.0
Protection Glass Thickness	3.2 mm (Anti-Glare)
Protection Glass Transmission	88%
Operating System Support	Windows 7 / 8 / 10 / Linux / Mac / Android (Supports one point touch on Linux / Mac)
Multi Touch Point	Max. 50 Points

Android System

CPU	Octa-core A73x4 +A53x4
GPU	Mali-G52 MP8
RAM	8 GB
Storage	64 GB
Wi-Fi	802.11 a/b/g/n/ac/ax (Wi-Fi 6E)
LAN	Gigabit LAN
Bluetooth	Bluetooth 5.3
OS ver.	Android 14(EDLA)

What is the LG TR3DQ interactive display used for?

The LG TR3DQ interactive display is designed for collaboration, presentations, and digital learning. This interactive screen is ideal for meeting rooms, classrooms, and training environments.

How many touch points does the LG TR3DQ interactive board support?

The LG TR3DQ interactive board supports up to 50 touch points, allowing multiple users to interact simultaneously on the interactive display for enhanced teamwork and collaboration.

What operating system does the LG TR3DQ interactive display use?

The LG TR3DQ interactive display runs on Android 14 (EDLA), enabling access to apps and tools directly on the interactive screen without additional devices.

What is the display quality of the LG TR3DQ interactive screen?

The LG TR3DQ interactive screen features 4K UHD resolution with 400 nit brightness, ensuring clear visuals and high-quality performance on the interactive display.
