LG-86TR3DK-BY

LG CreateBoard

Key Feature

Internal Memory : 64GB (Storage) / 8GB (RAM)
Brightness (w/o Glass) : 440 nit (Max.), 390 nit (Typ.)
Resolution : 3,840 × 2,160 (UHD)
Multi-Touch Point : 40 Points (Max.)

0.00 AED

SIZE
- 86"

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Specifications

SIZE

86"

SIZE: 86"

ultra HD interactive screen

4K interactive screen for sharp visuals and detailed content display

collaborative interactive board

supports group work, brainstorming, and interactive sessions

large format display solution

interactive display ideal for conference rooms and training spaces

powerful built-in system

interactive display with fast processing and smooth multitasking

LG 86TR3DK-BY Interactive Display – Large Format Interactive Screen in Dubai, UAE

The LG 86TR3DK-BY is a large-format interactive display designed to deliver powerful performance, seamless collaboration, and immersive visual experiences. Featuring an expansive 86-inch 4K UHD interactive screen with a resolution of 3,840 × 2,160, this interactive display ensures sharp visuals and detailed content presentation in professional environments.

With brightness levels up to 440 nit (max) and 390 nit (typical), the interactive screen maintains clear visibility across various indoor lighting conditions. The interactive board is powered by high-performance hardware, including 8GB RAM and 64GB internal storage, enabling smooth multitasking, application usage, and efficient workflow management.

At Logixer, we provide supply and installation of LG interactive displays across Dubai and the UAE, helping organizations upgrade their meeting rooms, classrooms, and collaboration spaces.

High-Performance Interactive Display

Powerful Internal Hardware

The LG interactive display is equipped with 8GB RAM and 64GB storage, ensuring fast performance for running applications, managing files, and conducting interactive sessions. This makes the interactive screen suitable for demanding business and educational environments.

Optimized for Modern Workflows

The interactive display supports smooth and efficient operation, allowing teams to collaborate, present, and interact without delays.

Advanced Touch and Collaboration Experience

40-Point Multi-Touch Interactive Screen

The interactive board supports up to 40 simultaneous touch points, enabling multiple users to interact on the interactive screen at the same time. This enhances teamwork, brainstorming, and group collaboration.

Natural Writing and Annotation

The interactive display delivers a precise and responsive touch experience, allowing users to write, draw, and annotate directly on the interactive screen with accuracy.

Stunning Visual Performance

4K UHD Interactive Display

The interactive display offers 4K Ultra HD resolution, ensuring clear and detailed visuals for presentations, training, and communication.

Bright and Wide Viewing Experience

With high brightness and wide viewing angles, the interactive screen provides consistent image quality from different positions in the room.

Smart Collaboration and Productivity

Built-in Collaboration Tools

The interactive board includes digital whiteboard features, annotation tools, and presentation capabilities, making it ideal for meetings and training sessions.

Seamless Content Sharing

The interactive display supports screen sharing and device connectivity, enabling users to present and collaborate efficiently.

Flexible and Scalable Design

Large Format Interactive Screen

The 86-inch interactive display is ideal for large meeting rooms, conference halls, and classrooms where visibility and engagement are essential.

Easy Integration

The interactive board integrates seamlessly with laptops, mobile devices, and enterprise systems, making it a versatile display solution.

Ideal Applications

The LG interactive display is suitable for:

• Corporate meeting rooms

• Large conference spaces

• Training and seminar rooms

• Educational institutions

• Smart classrooms

• Collaborative work environments

LG Interactive Display Supply and Installation in Dubai

At Logixer, we provide complete supply, installation, and technical support for LG interactive displays across Dubai and the UAE. Our team ensures smooth deployment of interactive screens and interactive boards tailored to your business needs.

The LG 86TR3DK-BY interactive display is a powerful and reliable solution for organizations looking to enhance collaboration, productivity, and digital interaction in modern workspaces.

Panel

Screen Size	86"
Panel Technology	IPS
Back Light Type	Direct
Aspect Ratio	16:09
Native Resolution	3,840 X 2,160 (4K UHD)
Refresh Rate	60 Hz
Brightness	440 nit (w/o Glass Max.), 390 nit (w/o Glass Typ.)
Contrast Ratio	1,200 : 1
Color gamut	NTSC 68%
Viewing Angle (H x V)	178 × 178
Color Depth	1.07 B (10 bit)
Response Time	8 ms
Surface Treatment (Haze)	25%
Lifetime	30,000 Hrs(L50, Min.), 50,000 Hrs (L30)
Operation Hours (Hours / Days)	16 / 7
Portrait / Landscape	No / Yes

Mechanical Specification

Bezel Color	Black
Bezel Width (T / R / L / B)	15 / 15 / 15 / 44 mm
Weight (Head)	58.6 kg
Packed Weight	75.9 kg
Monitor Dimensions (W × H × D)	1,957 × 1,160 × 100 mm
Carton Dimensions (W × H × D) (Box Outer Size)	2,110 × 1,283 × 225 mm
Handle	Yes
VESA™ Standard Mount Interface	800 × 600 mm

Environment Conditions

Operation Temperature	0 to 40°C
Operation Humidity	10% to 90%

Power

Power Supply	AC 100-240V~, 50/60Hz
Power Type	Built-In Power

Power Consumption

Typ./Max.	385 / 580 W
DPM	≤0.5W
Power off	≤0.5W
BTU (British Thermal Unit)	1,314 BTU/Hr (Typ.), 1,979 BTU/Hr (Max.)

Certification

Safety	CB / NRTL
EMC	FCC Class "A" / CE / KC
ErP / Energy Star	Yes / Yes

OPS Compatibility

OPS Type Compatible	Yes (Slot)
OPS Power Built In	Yes

Software Compatibility

LG ConnectedCare	Yes
LG ConnectedCare DMS	Yes

Connectivity

Input	HDMI (3, HDCP 2.2), RGB (VGA), Audio In, RS-232C In, RJ45 (LAN), USB 3.0 Type A (4), USB 2.0 Type A, USB Type C (USB-PD, DP-Alt)
Output	HDMI Out, Audio Out (1, Optical 1 (SPDIF)), Touch USB (2), RJ45 (LAN)

Sound

Speaker

Yes (15W × 2)

Language

English, Simplified Chinese, Czech, Denmark, Arabic(Egypt), Finnish, French, German, Greek, Italian, Korean, Netherlands(Dutch), Norwegian, Polski, Portugues(Europe), Portugues(Brazil), Romanian, Russian, Spanish, Swedish, Türkçe, Ukrainian, Traditional Chinese, Hungarian, Thai, Indonesian, Qajaq, Catalan, Basque

Accessory

Basic	Power Cord 3 M1, USB Cable (Type A-Type B) 5 M1, HDMI Cable 3 M1, Writing Pen2pcs, User Manual, QSG, Carton Box, Remote Controller(include battery 2ea), Wifi module
Optional	Wall Mount(WM-L000S), Floor Stand(ST-000F) (US only)

Touch

Available Object Size for Touch	Ø2 mm↑
Response Time	≤5 ms
Accuracy	±1 mm
Interface	USB 2.0
Protection Glass Thickness	3 T (Anti-Glare)
Protection Glass Transmission	88%
Operating System Support	Windows 7 / 8 / 10 / Linux / Mac / Android (Supports one point touch on Windows XP / Linux / Mac)
Multi Touch Point	Max 40 points (Windows), Max 32 points (Android)

Android System

SoC	Quad Core A55
GPU	Mali G52MP2
RAM	8 GB
Storage	64 GB
Wi-Fi	802.11a/b/g/n/ac/ax (Wi-Fi 6)
LAN	Gigabit LAN
Bluetooth	Bluetooth 5.0
OS ver.	Android 13

Key Feature

Internal Memory (64 GB), Built-In Wi-Fi (Slot Type), Auto Brightness Sensor, Power Indicator, Android 13, Background Image (Booting Logo Image), Multi-screen (PIP / PBP, External Source), Screen Share, Power (Smart Energy Saving, Wake on LAN)

What is the LG 86TR3DK-BY interactive display used for?

The LG 86TR3DK-BY interactive display is designed for collaboration, presentations, and interactive learning. This interactive screen is ideal for large meeting rooms, classrooms, and conference spaces.

How many touch points does the LG 86TR3DK-BY interactive board support?

The LG 86TR3DK-BY interactive board supports up to 40 touch points, allowing multiple users to interact simultaneously on the interactive display for better teamwork and collaboration.

What are the performance specifications of the LG 86TR3DK-BY interactive display?

The interactive display comes with 8GB RAM and 64GB internal storage, ensuring smooth performance for multitasking, applications, and presentations on the interactive screen.

What is the display quality of the LG 86TR3DK-BY interactive screen?

The LG 86TR3DK-BY interactive screen features 4K UHD resolution with up to 440 nit brightness, delivering clear visuals and high-quality performance on the interactive display.
